Gas Producer
Product Description:
Gas producer is mainly used in machine, metallurgy, non-ferrous metal, chinaware, glass, chemical industries.
Under the medium of gasification, heated through hearth, solid fuel produces flammable gas fixed with gas, which would be passing to the muzzle of heating treatment furnace by gas line for combustion to heat the work pieces.
Technical Parameters:
Gas producer is mainly used in machine, metallurgy, non-ferrous metal, chinaware, glass, chemical industries.
Under the medium of gasification, heated through hearth, solid fuel produces flammable gas fixed with gas, which would be passing to the muzzle of heating treatment furnace by gas line for combustion to heat the work pieces.
Technical Parameters:
|
Name
|
Gas Producer
|
|||||||||
|
Internal Diameter(m)
|
0.6
|
0.6
|
1
|
1.2
|
1.4
|
1.6
|
1.8
|
|||
|
Sectional Area (m³)
|
0.28
|
0.5
|
0.78
|
1.13
|
1.53
|
2
|
2.54
|
|||
|
Fuel Consumption (kg/h)
|
60-90
|
100-130
|
150-210
|
220-265
|
250-300
|
350-450
|
480-580
|
|||
|
Gas Production (Nm/h)
|
180/270
|
300/270
|
450/630
|
600/295
|
750/900
|
1050/1350
|
1440/1740
|
|||
|
Cleaner Way
|
Hand Cleaner
|
|||||||||
|
Internal Diameter(m)
|
2
|
2.2
|
2.4
|
2.6
|
2.8
|
3
|
3.2
|
|||
|
Sectional Area (m³)
|
3.14
|
3.29
|
4.52
|
5.3
|
6.15
|
7.06
|
8.03
|
|||
|
Fuel Consumption (kg/h)
|
600-850
|
900-1000
|
1000-1200
|
1200-1500
|
1600-1800
|
2400-2600
|
2400-2600
|
|||
|
Gas Production (nm³/h)
|
1800/2550
|
2700/3000
|
3000/3600
|
3600/4500
|
4800/5400
|
6000/7200
|
7200/7800
|
|||
|
Cleaner Way
|
Machine Cleaner
|
Worm Gear
|
||||||||
|
Fuel Standard
|
anthracite, bitumite, lignite, coke
|
|||||||||
|
Gasification Agent
|
Gas + Water
|
|||||||||
|
Gas Caloricity (KJ/nm³)
|
5025-5650(1200-1450 Kcal)
|
|||||||||
|
Gas Outlet Temperature(℃)
|
200-450 Can be adjusted according to the coal quality situation
|
|||||||||
|
Gas Outlet Pressure(Pa)
|
900
|
|||||||||
|
Saturation Temperature(℃)
|
45-70
|
|||||||||
|
Quality Of Coal
|
<70
|
|||||||||
|
Working Pressure
|
Heat should be over 6000 Kcal, per kilogram of coal can produce three cubic coal gas.
|
|||||||||
